Dee Shackle No 834 and No 835
Standard:
DNV 2.7-1 Type Approved, EN 13889 and U.S Fed. Spec. RR-C-271
Material:
High Tensile Carbon Steel, Quenched and tempered, Grade 6
Finish:
All parts hot dip galvanized, pin brown painted on top of galv.
Safety factor:
6:1
Documentation:
Test certificate and traceable raw material / inspection certificate acc. EN 10204 — 3.1.
DNV 2.7-1 and DNV 2.7-3 Type Approval Certification.
Temperature:
-20ºC to 200°C
Shackle No 834 with screw pin
Shackle No 835 with safety bolt
Art. no.
Screw pin
Art. no.
Safety bolt
WLL
tonnes
6:1
Dim.
d1
d Trade size
mm inch
Inner
width
a*
Inner
length
c*
Eye
outer
d2
Screw pin
kgs
Safety bolt
kgs
A083405
—
0.33
6
5
3/16”
10
22
13
0.02
—
A083406
—
0.5
8
7
1/4”
12
25
12
0.06
—
A083408
—
0.75
10
9
5/16”
13.5
27
16
0.11
—
A083409
—
1.0
11
10
3/8”
17
31
20
0.15
—
A083411
—
1.5
13
11
7/16”
18.5
37
22
0.21
—
A083413
A083513
2.0
16
13
1/2”
21
41
33
0.25
0.30
A083416
A083516
3.25
19
16
5/8”
27
51
40
0.55
0.60
A083419
A083519
4.75
22
19
3/4”
31
60
48
1.00
1.10
A083422
A083522
6.5
25
22
7/8”
37
71
52
1.30
1.50
A083425
A083525
8.5
28
25
1”
43
81
60
1.90
2.20
A083428
A083528
9.5
32
28
1 1/8”
46
90
64
2.80
3.10
A083432
A083532
12.0
35
32
1 1/4”
52
100
72
3.60
4.20
A083435
A083535
13.5
38
35
1 3/8”
57
111
76
4.60
5.60
A083438
A083538
17.0
42
38
1 1/2”
60
122
84
6.50
7.50
A083445
A083545
25.0
50
45
1 3/4”
74
149
105
11.50
13.00
A083452
A083552
35.0
57
50
2”
83
171
112
16.00
18.00
—
A083564
55.0
70
6
5
2 1/2”
105
203
145
—
39.00
* Forging tolerance: +/- 5% on inside width/length.
Split pin included
Похожие товары в ассортименте:
Dee Shackle No 834 and No 835: High-quality and Reliable Hardware for Heavy-Duty Applications
When it comes to heavy-duty applications, safety and reliability are of utmost importance. This is why choosing the right hardware is crucial to ensure the success of any project. The Dee Shackle No 834 and No 835 are two types of shackles that are widely used in various industries due to their superior quality and excellent performance.
Standard and Material
The Dee Shackle No 834 and No 835 are both compliant with the DNV 2.7-1 Type Approval, EN 13889, and U.S Fed. Spec. RR-C-271 standards. These standards ensure that the shackles are manufactured with the highest quality and meet the necessary safety requirements for their intended use.
Both shackles are made of high tensile carbon steel that has been quenched and tempered to Grade 6. This material is known for its strength, durability, and resistance to wear and tear. The shackles can withstand heavy loads and harsh environmental conditions, making them ideal for use in offshore and onshore applications.
Finish and Safety Factor
To further enhance the durability and longevity of the Dee Shackle No 834 and No 835, all parts are hot dip galvanized. This process provides a protective layer against corrosion, which is especially important for applications that involve exposure to saltwater. Additionally, the pin of the shackles is brown painted on top of the galvanization to indicate its position and ensure easy identification.
The safety factor of the Dee Shackle No 834 and No 835 is 6:1, which means that they can withstand six times their working load limit (WLL). This high safety factor provides an additional level of assurance that the shackles can handle heavy loads with ease.
Documentation and Temperature Range
The Dee Shackle No 834 and No 835 come with a test certificate and traceable raw material/inspection certificate according to EN 10204 — 3.1. This documentation ensures that the shackles have undergone rigorous testing and inspection to meet the necessary quality standards.
Both shackles have a temperature range of -20ºC to 200°C, which means that they can be used in a wide range of temperatures without compromising their performance.
Conclusion
The Dee Shackle No 834 and No 835 are excellent choices for heavy-duty applications that require superior quality and reliability. They are compliant with multiple standards, made of high tensile carbon steel, and have a hot dip galvanized finish with a brown painted pin for easy identification. With a safety factor of 6:1 and a temperature range of -20ºC to 200°C, these shackles are designed to withstand the toughest conditions and provide long-lasting performance.
